FNIRSI DSO-TC4 3-in-1 Handheld Digital Oscilloscope Multitester
Original price was: £74.00.£59.00Current price is: £59.00. & Free Shipping
Free shipping on orders over $50!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
3-in-1 Digital Oscilloscope, Transistor Tester & Signal Generator
The FNIRSI DSO-TC4 is a versatile 3-in-1 handheld instrument that combines a digital oscilloscope, comprehensive component tester, and DDS signal generator in one compact device. Designed for engineers, technicians, electronics enthusiasts, and repair professionals, this multifunctional tool delivers professional-grade performance in a portable form factor.
Key Features and Capabilities
- High-Performance Oscilloscope – 10 MHz analog bandwidth with 48 MSa/s real-time sampling rate for accurate signal capture and analysis. Maximum test voltage of 400V (with 10:1 probe) ensures versatility across various applications.
- Wide Vertical Sensitivity Range – Adjustable from 10mV/div to 10V/div (X1 range) with selectable AC/DC coupling modes and 1MΩ input impedance for comprehensive signal measurement.
- Flexible Time Base – Time base range from 50ns to 20s allows detailed observation of both fast transients and slow-changing signals with precision.
- Advanced Triggering System – Auto/Normal/Single trigger modes with rising and falling edge detection, plus adjustable trigger level with visual indication for stable waveform capture.
- Comprehensive Automatic Measurements – Instantly displays maximum, minimum, average, RMS, peak-to-peak voltage, frequency, cycle time, and duty cycle without manual calculations.
- Waveform Storage – HOLD function enables waveform freeze, storage, and export for documentation and further analysis.
- Versatile Component Testing – Automatically identifies and tests diodes (forward voltage drop <5V), NPN/PNP transistors, field-effect transistors (JFET, IGBT, MOSTET), SCRs (trigger voltage <5V), bidirectional SCRs (trigger current <6mA), and Zener diodes (0.01~4.5V).
- Comprehensive Passive Component Measurement – Tests capacitors (25pF to 1000μF), resistors (0.01Ω to 50MΩ), and inductors (10μH to 1000μH) with automatic pin identification and parameter display.
- 13 Waveform Signal Generator – Built-in DDS function generator supports 13 different waveform outputs with frequency range from 0 to 50kHz and adjustable output voltage up to 3V for versatile signal simulation.
- Flexible PWM Output – Square wave duty cycle adjustable from 0-100% and waveform amplitude from 0.1V to 3.0V for precise signal generation and testing.
- Sensor Interface Support – Compatible with DS18B20 temperature sensors and DHT11 temperature/humidity sensors for environmental monitoring applications.
- NEC Infrared Decoding – Supports NEC protocol infrared code decoding, making it ideal for debugging and repairing remote control devices.
Practical Applications
Circuit Development and Prototyping – Visualize circuit behavior in real-time, generate test signals, and verify component values all with a single instrument, streamlining the development process.
Electronics Repair and Troubleshooting – Quickly diagnose faulty components on circuit boards, test power supply ripple, verify signal integrity, and decode infrared remote controls during repair work.
Quality Control and Incoming Inspection – Rapidly test and verify electronic components before assembly, ensuring only quality parts enter production while identifying counterfeit or out-of-specification components.
Educational and Training Applications – An excellent teaching tool for electronics courses, allowing students to observe signal behavior, understand component characteristics, and practice measurement techniques.
Field Service and Maintenance – The portable design makes it perfect for on-site equipment testing, telecommunications work, industrial maintenance, and any application where multiple test instruments would be impractical.
Hobbyist and DIY Projects – Ideal for Arduino, Raspberry Pi, and electronics hobby projects where signal debugging, component testing, and waveform generation are frequently needed.
Enhanced Testing Efficiency
The DSO-TC4 features automatic calibration functionality that ensures consistent accuracy across all measurement modes. The one-key AUTO function allows for quick waveform display without manual adjustments, significantly reducing setup time. The continuity test function provides immediate audio-visual feedback for circuit connectivity verification, while the voltage measurement capability (up to 40V input with appropriate probe) adds further diagnostic versatility.
The intuitive 2.8-inch TFT color screen with LED backlight provides clear visualization of waveforms and measurement data, with adjustable brightness to suit different lighting environments. The dual input impedance of 1MΩ ensures minimal circuit loading during measurements.
Portability and Convenience
Compact and lightweight at approximately 186g with dimensions of 90×142×27.5mm, the DSO-TC4 is truly handheld and portable. The built-in 3.7V 1500mAh rechargeable lithium battery provides extended operating time for field work, with convenient TYPE-C charging (5V/1A). Energy-saving automatic shutdown options (15/30/60 minutes) help maximize battery life during intermittent use.
The device supports multiple languages including Chinese, English, Deutsch, Português, Japanese, Español, Korean, and Russian, making it accessible to users worldwide.
Complete Package
The DSO-TC4 comes with a comprehensive accessory package including a P6100 high voltage probe for safe measurements up to 400V, an alligator clip probe for general testing, three test hooks for component identification, an adapter, TYPE-C charging cable, carrying case, and detailed user manual.
In summary, the FNIRSI DSO-TC4 is an exceptional all-in-one diagnostic tool that eliminates the need for multiple separate instruments. Whether you’re troubleshooting circuits, testing components, generating signals, or teaching electronics principles, this versatile device delivers professional performance in a remarkably compact and affordable package.
Additional information
| Weight | 0.400 kg |
|---|---|
| Dimensions | 23 × 16 × 13 cm |
| Brand Name | FNIRSI |
| FNIRSI Model | DSO-TC4 |
| Battery Included | Yes |
| Origin | Mainland China |
| High-concerned chemical | None |
| DIY Supplies | Electrical |
| Model Number | DSO-TC4 |
| IS Battery Demountable | No |
| Certification | CE, EAC, RoHS, weee |
| Display screen | 2.4 inch TFT color screen |
| Supply voltage | Rechargeable lithium battery |
| Charging specifications | Type-C 5V |
| Bracket specifications | All-in-one foldable stand |
| Real-time sample rate | 10MSa/s |
| Analog Bandwidth | 500Khz |
| Input resistance | 1MΩ |
| Coupling method | AC/DC |
| Test voltage range | 400V |
| Vertical Sensitivity (x1) | 10mV-10V |
| Horizontal time base range | 1us-10s |
| Trigger mode | Auto / Normal / Single |
| Trigger type | Rising edge / Falling edge |
| Waveform Freeze | Yes |
| Automatic measurement | Yes |
| Diodes | Forward voltage drop <4.5V |
| Reglulated diode | 0.01~4.5V |
| MOSFET | JFET IGBT MOSFET |
| SCR | Turn-on voltage <5V, gate Pole trigger current <6mA |
| Capacitor | 5pF~100mF |
| Resistor | 0.01Ω~50MΩ |
| Inductor | 10uH~1000mH |
| Battery | 0.1~4.5V |
| Input voltage | 0~40V |
| DS18B20 | 0-85℃ |
| DHT11 | 0-60℃/5-95% |
| Infrared remote decoding | NEC protocol infrared code |
| Triangle wave | 1-10KHz/0-3.3V/50%, 1-10KHz/0-3.3V/50% |
| Square wave | 1-100KHz/3.3V/50% |
| Pulse wave | 1-100KHz/3.3V/0-100% |
| Ramp | 1-10KHz/0-3.3V/0-100% |
| DC | 0-3.3V |
